GENERAL PARAMETERS

Manufacturer:Changan vehicle
Level:compact car
Energy type:Pure electric
NEDC pure electric cruising range (km):365
Maximum power(KW):120
Maximum torque (N-m):245
Electric motor (Ps):163
L×W×H (mm):4740*1820*1530
Body type:4-door 5-seat sedan
Maximum speed (km/h):135
Official 0-100km/h acceleration (s):10.8
Energy equivalent fuel dissipation (L/100km):1.39

CAR BODY

Length (mm):4740
Width (mm):1820
Height (mm):1530
Wheelbase (mm):2700
Front track (mm):1555
Rear Track (mm):1566
Full loaded minimum ground clearance (mm):120
Approach angle(°):16
Departure angle (°):20
Ramp angle (°):13.7
Maximum gradability (%):22
Minimum turning radius (m):5.6
Body type:sedan
Maximum wading depth (mm):300
Number of doors (pieces):4
Number of seats (pieces):5
Luggage compartment volume (L):410
Curb weight (kg):1630
Maximum volume of luggage compartment (Kg):2005

ELECTRIC MOTOR

Motor type:Permanent magnet / synchronization
Motor total power (KW):120
Motor total torque (Nm):245
Front motor maximum power (KW):120
Front motor maximum torque (N-m):245
Number of drive motors:single motor
Motor layout:front
Battery Type:Lithium iron phosphate battery
Cell brand:CATL
NEDC pure electric cruising range(km):365
Battery capacity (kWh):44.43
power consumption per 100 kilometers (KWh/100km):12.3

GEARBOX

Number of gears:1
Transmissiontype:Fixed gear ratio
Short name:Electric vehicle single speed gearbox

CHASSIS STEERING

Drive mode:front engine front drive
Front suspension type:MacPherson independent suspension
Rear suspension type:Torsion beam non - independent suspension
Steering assist type:Electric assist
Body structure:load bearing

WHEEL BRAKING

Front brake type:ventilated disc
Rear brake type:Disk type
Parking brake type:Electronic parking
Front tire specification:205160 R16
Rear tire specification:205/60 R16
Spare tire specification:Non-full size

ACTIVE / PASSIVE SECURITY CONFIGURATION

Main/passenger seat airbags:Main seat/Passenger seat
Tire pressure monitoring:Tire pressure indicator
Seat belt not fastened:front row

ASSISTANCE / CONTROL CONFIGURATION

Front/rear radar:front-/rear

EXTERNAL / ANTI-THEFT CONFIGURATION

Wheel material:Aluminum alloy
Key type:remote key

SEAT CONFIGURATION

Seat material:Fuax Leather
:front/rear adjustment
Main seat adjustment mode:Backrest adjustment
:High/low adjustment (2 way)
Passenger seat adjustment mode:front/rear adjustment
:Backrest adjustment
Front/rear seat center armrest:front/rear-

MULTIMEDIA CONFIGURATION

Number of USB/Type-C interfaces:front 2/back 1

LIGHTING CONFIGURATION

Low beam light source:Halogen
High beam light source:Halogen

GLASS/REARVIEW MIRROR

Front/rear power windows:front/rear
:electrical control
:Rearview mirror heats
Internal rearview mirror function:Manual anti-glare
Interior makeup mirror:Main driver
Passenger seat

AIR CONDITIONER/REFRIGERATOR

Air conditioner temperature control mode:automatic air-conditioning
