GENERAL PARAMETERS

Manufacturer:Saic GM Chevrolet
Level:compact car
Energy type:Pure electric
Time to market:2021.11
NEDC pure electric cruising range (km):518
Maximum power(KW):130
Maximum torque (N-m):265
Electric motor (Ps):177
L×W×H (mm):4665*1813*1513
Body type:5-door 5-seat hatchback crossover
Maximum speed (km/h):170
Energy equivalent fuel dissipation (L/100km):1.43

CAR BODY

Length (mm):4665
Width (mm):1813
Height (mm):1513
Wheelbase (mm):2660
Front track (mm):1545
Rear Track (mm):1556
Approach angle(°):16
Departure angle (°):17
Body type:hatchback crossover
Number of doors (pieces):5
Number of seats (pieces):5
Luggage compartment volume (L):433-1077
Curb weight (kg):1620
Maximum volume of luggage compartment (Kg):2080

ELECTRIC MOTOR

Motor type:Permanent magnet / synchronization
Motor total power (KW):130
Motor total torque (Nm):265
Front motor maximum power (KW):130
Front motor maximum torque (N-m):265
Number of drive motors:single motor
Motor layout:front
Battery Type:Ternary lithium battery
NEDC pure electric cruising range(km):518
Battery capacity (kWh):61.1
power consumption per 100 kilometers (KWh/100km):12.6

GEARBOX

Number of gears:1
Transmissiontype:Fixed gear ratio
Short name:Electric vehicle single speed gearbox

CHASSIS STEERING

Drive mode:front engine front drive
Front suspension type:MacPherson independent suspension
Rear suspension type:Multi-link independent
:suspension
Steering assist type:Electric assist
Body structure:load bearing

WHEEL BRAKING

Front brake type:ventilated disc
Rear brake type:Disk type
Parking brake type:Electronic parking
Front tire specification:215/55 R17
Rear tire specification:215/55 R17
Spare tire specification:None

ACTIVE / PASSIVE SECURITY CONFIGURATION

Main/passenger seat airbags:Main seat/Passenger seat
Front/rear side airbags:Front/Rear-
Tire pressure monitoring:Tire pressure indicator
Seat belt not fastened:front row

ASSISTANCE / CONTROL CONFIGURATION

Front/rear radar:front-/rear
Parking camera system:Reverse image
Cruise system:Cruise Control
sports
Driving mode switching:economy
Standard
Comfort

EXTERNAL / ANTI-THEFT CONFIGURATION

Wheel material:Aluminum alloy
Key type:remote key
bluetooth key

SEAT CONFIGURATION

Seat material:Fuax Leather
front/rear adjustment
Main seat adjustment mode:Backrest adjustment
High/low adjustment (2 way)
Passenger seat adjustment mode:front/rear adjustment
Backrest adjustment
: Rear seats folded down:ratio down
Front/rear seat center armrest:front/rear-

MULTIMEDIA CONFIGURATION

Center console large screen:Touch LCD screen
Center console screen size: 10.1 inches
Mobile phone interconnection/mapping:CarPlay
CarLife
Voice recognition control: multimedia system
navigation
phone call
air conditioner
Vehicle-mounted intelligent system:Koyuki OS
4G/5G network: 4G
USB
Multimedia/charging interface: AUX
SD
Number of USB/Type-C interfaces:front 2/back 2

LIGHTING CONFIGURATION

Low beam light source: LED
High beam light source: LED

GLASS/REARVIEW MIRROR

Front/rear power windows:front/rear
One key Windows lifting function:Whole car
Multilayer soundproof glass  :Front row
electrical control
Internal rearview mirror function  :Manual anti-glare
Interior makeup mirror  :Main driver + lights
Passenger seat + light

AIR CONDITIONER/REFRIGERATOR

Air conditioner temperature control mode  :automatic air-conditioning
